Precision measurement, professional weighing
manufacturer with temperature compensation technology
Features:
Electromagnetic force transducer
Halogen lamp heat source
Removable stainless steel weighing pan
Backlit LCD display
Overload and underload alarms
Temperature compensation and timed calibration
Applications:
Weighing,Percent Moisture Determination
Construction:
Halogen heat source,metal base, ABS top housing
Stainless steel pan support,stainless steel pan handler,in-use cover
Specifications:
|
Model |
LSC50A |
|
Heating Source |
Halogen Lamp(Ring 500W) |
|
Make |
LT |
|
Capacity |
50 g |
|
Min Capacity of Sample |
5 g |
|
Readability |
0.0001 g(0.1 mg) |
|
Repeatability(±) |
0.0001 g |
|
Linearity(±) |
0.0002 g |
|
Display |
LCD Display |
|
Pan Size |
φ90 mm |
|
Sensor |
Electromagnetic Force Sensor |
|
Calibration |
Automatic External |
|
Drying Method |
Standard,Fast,Step |
|
Measuring Method |
Automatic,Manual,Time-defined,User-defined |
|
Operating Temperature |
10℃ to 40℃ |
|
Temp.Sensor |
PT-100 |
|
Interface |
RS232C |
|
Temp.Range |
60-200℃ |
|
Temp.Step |
1℃ |
|
Time Setting |
1~99 minutes |
|
Dry Readability |
0.01% |
|
Dry Range |
100.00%～0.00% |
|
Aluminium Sample Pan |
10 Pcs Available |
|
Power Supply |
AC 220V/50-60 Hz |
|
Dimension(LxW×H) |
460×380×300 mm |
|
Weight |
4.5 kg |
|
MOQ |
1 Set |
|
Customs Tariff Number |
9027899090 |
Note:
Standard Accessories: Main Instrument,Weighing Pan,Ring,Power Adaptor,Aluminium Sample Pan,Antivibration Pad,Test Certificate
MOQs
1.What Are Moisture Analyzers?
Moisture analyzers are advanced laboratory devices that combine weighing and moisture analysis. They are essential in chemical, pharmaceutical, and food research, where determining water content in samples is crucial.
2.How Do Moisture Analyzers Work?
Unlike standard laboratory balances, moisture analyzers are equipped with a heating element (halogen) that removes moisture from a sample by heating it.
The device then calculates the post-drying weight and determines moisture content.
3.What are the advantages of halogen heating?
The most important performance factor is precise and fast temperature regulation, which is best delivered by halogen lamps because of their low mass and therefore fast reaction time.
This ensures repeatable results starting from the first measurement (some other heating sources either deliver different results in the first measurement or require a warm up measurement, which wastes time and resources).
Furthermore, an even heat distribution on the sample surface is essential for repeatable and reliable results.
We advise you to ask us or another manufacturer for a demonstration in order to experience the performance in real-life.
4.Why Choose LT Moisture Analyzers?
Moisture analyzers from Longteng guarantee precise measurements and reliability.
They are perfect for research laboratories, food industry, and pharmaceuticals.
